Simcenter measurement system with power-cycling function

Simcenter POWERTESTER - 1500A / 8V / 3 (12)

Simcenter POWERTESTER - 1500A / 8V / 3 (12)

MG288824NO

The Simcenter POWERTESTER measurement system. This hardware can perform thermal transient measurements, including power cycling of power transistors at 1500 A at 8 V up to 3 A, with a maximum of 12 channels.

Requirements - MG286670MC

  • Non-destructive thermal characterization with precise measurement parameters
  • Reliability studies using accelerated life tests and various power-cycling routines
  • Built-in safety features

Frame Color
€128,950.00
€128,950.00
Sale Sold out
You need a verified account to view prices and purchase products.
  • Available
Show full details
  • Number of heating current outputs:
  • 3
  • Output current:
  • Max. 1800 A (3 x 600 A)
  • Output voltage:
  • Max. 12 V
  • Output power:
  • Max. 21 kW
  • Measurement points:
  • 12 (3x4)
  • Cooling:
  • 2 cooling plates (30 cm x 40 cm) with test specimen holder
  • Safety precautions:
  • autonomous system monitoring unit
  • Possible examinees:
  • Diode, IGBT, Si MOSFET, SiC MOSFET
  • With an integrated test cell and cooling plates
