Input module

Simcenter SCADAS Mobile 2-channel wheel force interface module with Kiroad and Roadyn support

Simcenter SCADAS Mobile 2-channel wheel force interface module with Kiroad and Roadyn support

SCM-WFI2-KR

The WFI2-KR is a two-channel digital interface module designed for connection to the Kistler Roadyn® 2000 and the KiRoad Performance wheel force transducer system. All relevant wheel force signals are recorded synchronously via a UTP connection.

  • Support for two Kistler ROADYN2000® or KiRoad frames per module
  • A combination of a total of eight complete wheel force transducers
  • Synchronous acquisition of WFT signals without any loss of accuracy due to clock drift.

€11,210.00
€11,210.00
Sale Sold out
You need a verified account to view prices and purchase products.
  • Available
Show full details

The WFI2-KR is a two-channel digital interface module designed to connect the KISTLER ROADYN® 2000 and the KiRoad Performance Wheel Force Transducer System. It supports synchronous acquisition of all relevant wheel force signals via a UTP connection:



Forces in the X, Y, and Z directions
- Moments in the X, Y, and Z directions
- Angles and angular velocity
- Wheel temperature
- Internal power supply



A single WFI2-KR module supports up to two ROADYN 2000 or KiRoad racks and allows simultaneous access to up to 8 wheel force sensors per module.

  • Two 50-cm BNC adapter cables
  • Two 2-meter STP07 CAT Ethernet cables
